TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 185
Hard disk drives / solid state drives
7.2 2.5-inch HDD / SSD configurations
7.2.1 2.5-inch HDD / SSD backplane overview
Figure 91: 2.5-inch SAS backplanes - Rack version
Figure 92: 2.5-inch SAS backplanes - Tower version
1 / 2 SAS backplanes 1 and 2 in HDD cage 1 (basic configuration)
3 / 4 SAS backplanes 3 and 4 in optional HDD cage 2
5 / 6 SAS backplanes 5 and 6 in optional 8x 2.5-inch HDD extension box
