TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 559
Accessible drives
12.5.1.6 Cabling the slimline ODD and LSD
I The cabling list number and cabling plan sections in the allocation tables
below refer to chapter "Cabling" on page 735.
Slimline SATA ODD
Local Service Display (LSD)
Ê Connect the LSD, SATA and power cables as shown in the tables above.
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
SATA cable
Y3958-V205
20 Slimline ODD
System board
connector SATA 1
16.2.1
Slimline ODD SATA
power cable
Y3986-V302
8A / 8B
Slimline ODD
(15-pin SATA)
3.5-inch HDD
backplane 2
connector X9
(4-pin connector)
16.2.6
16.2.4
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
LSD cable
Y3718-V301
14 LSD
System board
connector SMB 1
16.2.1
