7.5.3 Replacing the SAS expander board
7.5.3.1 Preliminary steps
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê "Opening the server" on page 68
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
Ê Remove all cables from the SAS expander board.
7.5.3.2 Removing the defective SAS expander board
Ê "Removing the SAS expander board" on page 315.
7.5.3.3 Installing the new SAS expander board
Ê "Installing the SAS expander board" on page 309.
Field Replaceable Unit
(FRU)
Average task duration:
10 minutes
Tools: tool-less
