7.3.8.2 Removing a 3.5-inch HDD module
Ê Remove the HDD module to be replaced from the server as described in
section "Removing a 3.5-inch HDD module" on page 259.
7.3.8.3 Installing a 3.5-inch HDD module
Ê Install the new HDD module into the empty drive bay as described in section
"Installing 3.5-inch HDD modules" on page 254.
7.3.8.4 Concluding steps
Ê When working on a tower server, close the HDD bay cover as described in
section "Installing accessible drive and HDD bay covers" on page 105.
Ê Please observe the notes on RAID rebuild in section "Performing a RAID
array rebuild" on page 153.
7.3.9 Replacing a 3.5-inch HDD SAS backplane
7.3.9.1 Preliminary steps
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê Remove all HDD modules from the server as described in section
"Removing 3.5-inch HDD modules" on page 258.
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê "Opening the server" on page 68
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
Upgrade and Repair Unit
(URU)
Average task duration:
15 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
