Ê "Removing the system air duct" on page 81
Ê "Removing processor heat sinks" on page 523
11.3.2 Removing a processor
I This description applies to the following procedures:
– Removing CPU 2 from a dual-processor configuration
– Removing CPUs from a defective system board (see section
"Swapping processors" on page 695)
Ê Remove the desired processor heat sink as described in section "Removing
processor heat sinks" on page 523.
Figure 375: Opening socket release lever 1
Ê Unlatch the socket release lever marked Open 1st by pushing it down and
away from the socket (1).
Ê The socket release lever will slightly lift up (2).
