7.5.1.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 125
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê "Opening the server" on page 68
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
7.5.1.2 Installing SAS expander board spacer bolts
I This step is only necessary if SAS expander board spacer bolts are not
already mounted in the system. Otherwise, please proceed to section
"Installing the SAS expander board" on page 312.
Ê Remove the system board as described in section "Removing the system
board" on page 687.
Ê Remove the system board carrier as described in section "Removing the
system board carrier" on page 85.
Field Replaceable Unit
(FRU)
Average task duration:
additional 30 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
