Ê Insert (1) and close the PCI slot bracket locking bar (2) until the latch locks
in place (see close-up).
9.2.2.4 Concluding steps
Ê "Installing the system air duct" on page 83
Ê "Closing the server" on page 98
Ê When working on a rack-mounted server:
"Mounting the server in the rack" on page 115
Ê "Connecting the server to the mains" on page 118
Ê If BitLocker functionality is used and has been disabled before starting the
maintenance task: "Resuming BitLocker functionality" on page 152
9.2.3 Replacing expansion cards
Note on network settings recovery
I When replacing network controllers or the system board, network
configuration settings in the operating system will be lost and replaced
by default values. This applies to all static IP address and LAN teaming
configurations.
Ensure to note down your current network settings before replacing a
controller or the system board.
9.2.3.1 Preliminary steps
Ê If applicable, ensure to note down your current network settings in the
operating system. For further information, please refer to section "Note on
network settings recovery" on page 361.
Ê "Suspending BitLocker functionality" on page 125
Ê "Disabling SVOM boot watchdog functionality" on page 127
Upgrade and Repair Unit
(URU)
Average task duration:
10 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
