7.2.6 Installing 2.5-inch HDD / SSD modules
7.2.6.1 Preliminary steps
Ê When working on a tower server, open the HDD bay cover as described in
section "Removing accessible drive and HDD bay covers" on page 77.
Ê Locate the correct drive bay as described in section "2.5-inch HDD / SSD
configurations" on page 185.
7.2.6.2 Removing a 2.5-inch HDD / SSD dummy module
Figure 108: Removing a 2.5-inch dummy module
Customer Replaceable Unit
(CRU)
Average task duration:
5 minutes
Tools: tool-less
