7.4.5.6 Installing HDD modules into the 4x 3.5-inch HDD extension box
Ê "Closing the server" on page 98
Ê Install HDD modules or HDD dummy modules into the additional HDD slots
as described in sections "Installing a 3.5-inch HDD module" on page 256
and "Installing a 3.5-inch HDD dummy module" on page 261.
I For detailed information on HDD mounting order, refer to section "3.5-
inch HDD configurations" on page 241.
7.4.5.7 Concluding steps
Ê "Installing the system fan holder" on page 331
Ê "Installing the system air duct" on page 83
Ê "Closing the server" on page 98
Ê When working on a rack-mounted server:
"Mounting the server in the rack" on page 115
Ê "Connecting the server to the mains" on page 118
Ê If BitLocker functionality is used and has been disabled before starting the
maintenance task: "Resuming BitLocker functionality" on page 152
7.4.6 Removing the 4x 3.5-inch HDD extension box
7.4.6.1 Preliminary steps
Ê "Suspending BitLocker functionality" on page 125
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê Remove all HDD modules from the HDD extension box as described in
section "Removing 3.5-inch HDD modules" on page 258.
Upgrade and Repair Unit
(URU)
Average task duration:
10 minutes
Tools: tool-less
