TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 743
Cabling
16.2.6 Power cabling with 8x 3.5-inch HDDs and
2x 3.5-inch HDD extension box
Figure 582: Power cabling: 8x 3.5" HDDs and 2x 3.5" HDD extension box
System Board D2949
PSU CONTROL
PWR
Power Backplane
X25
X21
X20
X22 / X23
PWR HDD / ODD
4x 3.5-inch HDD
Backplane 1
X9
X10
X7
4x 3.5-inch HDD
Backplane 2
X9
X10
X7
Drive Bays 2-3
2x 3.5-inch
HDD Extension Box
HDD Backplane
Slimline ODD
X4
LSD
P1
1
3
P2
8A
