384 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Expansion cards and backup units
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
9.4.2.3 Connecting GPGPU / coprocessor card power cables to the
power backplane
Preliminary steps
Ê Remove the system board as described in section "Removing the system
board" on page 687.
Ê Remove the system board carrier as described in section "Removing the
system board carrier" on page 85".
Field Replaceable Unit
(FRU)
Average task duration:
additional 30 minutes
Tools: Phillips PH2 / (+) No. 2 screw driver
Coprocessor /
GPGPU card
Required power cable Cabling plan
Intel Xeon Phi 3120P T26139-Y3952-V701 16.2.22
Intel Xeon Phi 31S1P T26139-Y3952-V701 16.2.22
Intel Xeon Phi 5110P T26139-Y3946-V701 16.2.21
Intel Xeon Phi 5110P T26139-Y3946-V701 16.2.21
Intel Xeon Phi 7120P T26139-Y3952-V701 16.2.22
Nvidia TESLA K20 T26139-Y3946-V701 16.2.21
Nvidia TESLA K20X T26139-Y3946-V701 16.2.21
Nvidia TESLA K40 T26139-Y3946-V701 16.2.21
Nvidia GRID K1 T26139-Y3946-V701 16.2.21
Nvidia GRID K2 T26139-Y3946-V701 16.2.21
