8.3.3 Replacing rear fan modules
8.3.3.1 Preliminary steps
Ê "Locating the defective server" on page 57
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê Open the side / top cover as described in section "Opening the server" on
page 68.
Ê Locate the defective fan using the onboard Local Diagnostic LEDs as
described in section "Onboard indicators and controls" on page 779.
8.3.3.2 Removing rear fan modules
Ê Remove the defective rear fan module(s) as described in section "Removing
rear fan modules" on page 335.
8.3.3.3 Installing rear fan modules
Ê Replace the defective rear fan module(s) as described in section "Installing
rear fan modules" on page 332.
8.3.3.4 Concluding steps
Ê "Closing the server" on page 98
Ê When working on a rack-mounted server:
"Mounting the server in the rack" on page 115
Ê Reconnect all external cables to the server rear.
Ê "Connecting the server to the mains" on page 118
Ê Switch on the server.
Ê "Performing a fan test after replacing a defective fan" on page 145
Customer Replaceable Unit
(CRU)
Average task duration:
5 minutes
Tools: tool-less
