Ê Reinstall the SAS RAID controller as described in sections "Installing the
SAS RAID controller" on page 426 or "Installing expansion cards" on
page 349.
Ê Connect the SAS cables to their original connectors on the SAS RAID
controller.
9.6.3.3 Preparing the FBU
Figure 342: Installing the FBU in the FBU holder (A)
Ê At a slight angle, fit the FBU (A3C40137317) under both retaining brackets
of the FBU holder (C26361-K644-C970) as shown.
Ê Push in the FBU until it locks in place.
