TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 773
Appendix
17.1.3 Server interior
Figure 613: PRIMERGY TX300 S8 / RX350 S8 interior (example: 2.5-inch HDD tower model)
8
Shared LAN connector
(LAN 1)
"I/O panel connectors" on page 781
"I/O panel indicators" on page 782
"Replacing the system board" on
page 684
9
Standard LAN connectors
(LAN 2)
10
Management LAN
connector
11 Video connector (VGA) "I/O panel connectors" on page 781
12
Expansion cards
(slots 6-9) for GPGPU
cards
"Replacing a GPGPU / coprocessor card"
on page 424
