9.6.2 Installing a BBU
V CAUTION!
For further safety information, please refer to chapter "Important
information" on page 45.
9.6.2.1 Preliminary steps
Ê "Disabling SVOM boot watchdog functionality" on page 127
Ê "Shutting down the server" on page 62
Ê "Disconnecting the server from the mains" on page 63
Ê When working on a rack-mounted server:
"Extending / removing the server from the rack" on page 64
Ê Open the side / top cover as described in section "Opening the server" on
page 68.
Ê "Removing the system air duct" on page 81
Ê "Removing the system fan holder" on page 330
Ê "Removing the SAS expander board" on page 315 (if applicable)
1 Mounting position for first BBU / FBU
2 Mounting position for second BBU / FBU
3 Mounting position for third BBU / FBU
Upgrade and Repair Unit
(URU)
Average task duration:
5 minutes
Tools: tool-less
