246
Upgrade and Mai
ntenance Manual
TX300 S
8 / RX350 S8
Hard disk drives / solid st
ate drives
7.3.3.3
HDD naming
scheme
Figure 151: Naming scheme: 8x 3.5-inch HDDs (2 SAS backplanes)
Posit
ion
Logical drive
numbe
r
ServerView RAID
Manager display name
[1]
0
HDD vendor nam
e (0)
[2]
1
HDD vendor nam
e (1)
[3]
2
HDD vendor nam
e (2)
[4]
3
HDD vendor nam
e (3)
[5]
4
HDD vendor nam
e (4)
[6]
5
HDD vendor nam
e (5)
[7]
6
HDD vendor nam
e (6)
[8]
7
HDD vendor nam
e (7)
