TX300 S8 / RX350 S8 Upgrade and Maintenance Manual 245
Hard disk drives / solid state drives
7.3.3.2 8x 3.5-inch HDD SAS backplane cabling
I Before connecting SAS cables to the controller, bend the cables as
needed in order to reduce strain on the controller. Bend the SAS cables
as close to their shrink tubes as possible.
SAS cabling
Power cabling
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
SAS cable
Y3963-V151/V101
16
Connector MLC 1 on
SAS controller 1 in
PCI slot 10
SAS backplane 1
connector X1
16.2.7
SAS cable
Y3963-V153/V103
17
Connector MLC 2 on
SAS controller 1
PCI slot 10
SAS backplane 2
connector X1
16.2.7
Cable
(T26139-)
Cabling
list no.
from to
Cabling
plan
HDD power cable
Y3952-V601
1
Power backplane
connector X21
SAS backplane 1
connector X7
(HDDs 1, 3, 5, 7)
Cable connector P1
16.2.2
SAS backplane 2
connector X7
(HDDs 2, 4, 6, 8)
Cable connector P2
