7.4.10.2 Removing the 8x 2.5-inch HDD extension box
Ê Unlock and pull the 8x 2.5-inch HDD extension box out of its installation bays
as described in section "Removing the 8x 2.5-inch HDD extension box" on
page 306.
7.4.10.3 Installing the 8x 2.5-inch HDD extension box
Ê Install the new 8x 2.5-inch HDD extension box as described in section
"Installing the 8x 2.5-inch HDD extension box" on page 302.
7.4.10.4 Concluding steps
Ê "Installing the system fan holder" on page 331
Ê "Installing the system air duct" on page 83
Ê "Closing the server" on page 98
Ê Reinstall all hard disk drives into their original slots in the HDD extension box
as described in section "Installing 2.5-inch HDD / SSD modules" on
page 207.
Ê When working on a rack-mounted server:
"Mounting the server in the rack" on page 115
Ê "Connecting the server to the mains" on page 118
7.5 SAS expander board
7.5.1 Installing the SAS expander board
Field Replaceable Unit
(FRU)
Average task duration:
10 minutes
Tools: tool-less
