Fujitsu PRIMERGY TX300 S8 - Installing the GPGPU; Coprocessor Card Mounting Bracket

392 Upgrade and Maintenance Manual TX300 S8 / RX350 S8
Expansion cards and backup units
9.4.2.6 Installing the GPGPU / coprocessor card mounting bracket
Figure 274: Installing the coprocessor card mounting bracket (Intel) (A)
Figure 275: Installing the GPGPU card mounting bracket (Nvidia) (A)
Ê Place the GPGPU / coprocessor card mounting bracket in the gap next to
PCI slot 9 (1).
Ê Tilt the upper edge of the mounting bracket toward the chassis wall (2).
for Intel
for Nvidia
