4 NC-SI NCSI connector for Modular LAN cards
5 SAS 1-4
Onboard SAS connector (needs to be enabled
with onboard SAS enabling key)
6 USB STICK (not used)
7 SMB 4 (not used)
8 SATA 1 SATA connector for accessible SATA drives
9 INTRUSION Intrusion switch cable connector
10 FAN1 Fan connector for hot-pluggable system fan
11 SATA 2 SATA connector for accessible SATA drives
12 UFM Connector for USB Flash Module (UFM)
13 UPG-ROM
Connector for onboard SAS enabling key (required
to enable onboard SAS connector SAS 1-4)
14 FAN2
Fan connectors for hot-pluggable system fans15 FAN3
16 FAN4
17 TPM Connector for Trusted Platform Module (TPM)
18 USB INT 2
USB 2.0 connectors for USB backup drives
19 USB INT 1
20 SMB 1 Connector for Local Service Display (LSD)
21 FRONTPANEL
Connector for front panel and front USB
connectors
22 FRONT VGA Connector for optional front VGA connector
23 FRONT LAN Slot for front LAN connector board
24 PWR HDD/ODD
Power connector for HDD backplane or accessible
drives
25 PWR System power connector
26 PSU CONTROL Management connector for PSU modules
27 microSD iRMC microSD card slot
No. Print Description
