Furuno NavNet TZtouch3 Series User Manual

4. POINTS, BOUNDARIES
4-23
Circle boundary
1) Tap the location for the circle area. A yellow circle appears with circle resizing
icons. Drag the icons to change the location and radius of the circle.
2) After arranging the circle, tap [End Boundary] at the top-right corner.
Line boundary
1) Tap the location for the next point of the area. A yellow line runs between the
1st location and the 2nd.
2) Tap the location for the next point of the area.
Repeat this step to complete the area. You can drag an icon to change the po-
sition of a point.
3) After selecting the ending point, tap [End Boundary] at the top-right corner.
The boundary line is placed at the center of the screen.
Method 2: How to create a boundary from the Boundaries list
1. On the Home screen, tap [Lists]→[Boundaries] to show the [Boundaries] list.
2. At the top of the screen, tap [Add Area] or [Add Line] depending on the type of
boundary you want to make.
3. Use the software keyboard to enter the latitude and longitude position of the start-
ing point, then tap [9].
The point entered at center of the preview screen.
4. Tap[ Add Point].
5. Enter the latitude and longitude position of the next point, then tap [9].
Repeat this step to complete the boundary.
6. Tap [<] on the title bar to go back one layer in the menu.
7. Refer to section 4.17.5 to edit the boundary.
8. Tap the close button on the title bar to finish.
4.17.2 How to show or hide all boundaries
On the Layers menu, turn [Boundaries] [ON] or [OFF].
Resize icon
Drag to resize the
radius of circle.
Reposition icon
Drag to reposition
the circle.
Point #1
(starting point)
Point #2
Point #3
Point #5
(ending point)
Point #4
