Furuno NavNet TZtouch3 Series User Manual

2. CHART PLOTTER
2-26
[Radar Overlay]
[Radar Transparency]: Set the degree of transparency for the radar echo.
[Range Link]: Activate or deactivate matching the overlay with radar ranges.
[Echo Color]: Tap the color for the radar echo.
Depth Shading Values
[Depth Shading Transparency]: Set the degree of transparency for the depth shading
overlay.
For the menu items shown in the table, see the mentioned section.
[Restore Default Settings]: Tap this menu item to restore default settings for the [Plot-
ter Display] menu.
2.13 NAVpilot Series Auto Pilot
This section shows you to how to enable use of the NAVpilot with your system. For
how to use the NAVpilot to steer to a point, see subsection 4.15.4.
The FURUNO NAVpilot Series Auto Pilot installs in the NavNet TZtouch3 network to
get automatic steering when going to a point or a route. The following NAVpilot func-
tions can be controlled from a NavNet TZtouch3 display:
• Control operation of the NAVpilot from this equipment (see subsection 2.13.2).
• Select the NAVpilot steering mode (AUTO or NAV), referring to the NAVpilot’s Op-
erator’s Manual.
• Set up the NAVpilot (see subsection 2.13.4).
Note 1: When an alarm message for the NAVpilot appears, check the control unit of
the NAVpilot.
Note 2: To enter points or routes from your NAVpilot series Auto Pilot, see section
section 4.15.4 and section 5.11.11.
2.13.1 How to enable use of the NAVpilot
Open the [Settings]→[Routes] menu, then turn on [Navigate with AutoPilot]. When you
set a route or point as destination, the message" Do you want to navigate using the
NAVpilot?" appears.
Menu item Reference
[3D Display]
• [Auto 3D Alti Exaggeration]
• [3D Alti Exaggeration]
See subsection 3.1.2.
[Depth Shading Values]
• [Auto Depth Shading Color Scale]
• [Minimum Value]
• [Maximum Value]
• [Depth Color Shade]
See subsection 3.2.1.
