10. CAMERA/VIDEO/EXTERNAL EQUIPMENT

10-2

10.2 Video Signal Types

There are five types of video signals which can be connected to this equipment.

Compatible FLIR cameras

The following FLIR cameras are compatible the multi function display. (As of 4/2019.)

Note: The ClearCruise

™

function of FLIR cameras is inoperative with the multi func-

tion display.

Camera display combinations

The images from a maximum of two cameras can be displayed simultaneously.

Note: The images from two analog cameras cannot be displayed simultaneously.

See the table below for the combination of cameras that can show their images simul-

taneously.

• Digital signal (HDMI): Images from surveillance cameras, on-board cameras and

video playback.

Note: This feature is available with TZT16F/19F.

• Analog signal: Images from surveillance cameras, on-board cameras and video

playback.

• Digital signal (IP): Images from a network camera.

Note: Turn on the network camera first, then turn on the MFD.

• Axis Quad Server: The image from an Axis Quad Server, which can feed up to four

lines of video signals simultaneously.

• FLIR: Images from a FLIR brand infrared camera

Type Model

IP camera M132, M232

Analog camera M400, M400XR, M500, M324S, M324CS, M617CS, M625S, M625CS

Analog

IP Cam-

era

Cam-

era 2

Camera

Axis

Quad

Server

Sec-

ond

Axis

Quad

Server

HDMI

Input

Analog 1 No No Yes Yes Yes Yes Yes Yes Yes

Analog 2 No No Yes Yes Yes Yes Yes Yes Yes

IP Camera
