9. FILE OPERATIONS

9-2

[TZD]: For NavNet TZtouch2

[CSV]

: For NavNet3D

[GPX]

: For use with PC plotter

: The CSV format has the following export restrictions:

: When exporting data in GPX format, it is recommended to make a note of the

data contained in the file. GPX files names do not indicate their contents.

4. Tap the close button on the title bar to finish.

9.2 How to Export User Objects

This unit holds a maximum of 30,000 points, 200 routes, 100 polygon areas, (bound-

aries), 100 circles (boundaries), 1,000 screenshots, and 1,000 catches. When the ca-

pacity for routes/points is full, new data cannot be stored. If you need to save the

above-mentioned items permanently, save them to a media, following the procedure

below.

1. Put the appropriate formatted media in the USB port.

2. Open the Home screen, then tap [Settings]→[Files]→[Export User Objects].

3. A confirmation message asks you if you are sure to proceed.

4. Tap [OK]. The message "EXPORT SUCCEEDED" appears if the exporting was

successful.

5. Tap [OK] to erase the message.

6. Tap the close button on the title bar to finish.

9.3 How to Import User Objects

You can import points, routes and boundary lines to the internal memory of this unit,

using a SD card, microSD card or USB flash memory.

1. Put the appropriate formatted media in the USB port.

2. Open the Home screen, then tap →[Files]→[Import User Objects]. A list of files

stored on the inserted media appears.

3. Tap the file(s) to import. You are asked if you are sure to import selected items.

• Points: Max. 2,000

• Routes: Max. 200 (100 points/route)

• Track: Max. 10,000

USB 1

XXXX. XXX.tzx
