12. INSTRUMENT-RELATED DIS-
PLAYS
With connection of appropriate sensors, this equipment provides three types of spe-
cialized displays:
Instrument display: This display provides conventional navigation and environment
data. Analog and digital displays, highway display, NAVpilot data, etc. can be shown.
The display can be programmed to a full screen or three-way split screen.
CZone display: This display offers, in a full screen display, control of the Power Prod-
ucts’ CZone equipment (shipboard power management system) connected in the
NavNet network.
Yamaha engine status display: This display provides engine information about com-
patible Yamaha engines, in a full screen display.
12.1 How to Show the Instrument Display
Set the instrument display on the Home screen referring to subsection 1.7.1. Tap the
instrument display icon to show the instrument display.
Monday, January 1, 2018
Instrument display
(full screen)
Instrument display
(3-way screen)
To Next Page
