GP-330B
FI-50/70
IF-NMEA2K2
FA-30/50
FAX-30
DC12-24V
DC24V
SCX-20
SC-30/33
IF-NMEAFI
FAR-2xx7/2xx8 series
FAR-15x3/15x8 series
BBDS1, DFF series
FUSION-Link compatible devices
Autopilot
NAVpilot-300/
NAVpilot-711C
IP Camera
Radar Sensor (Radome)
DRS4DL/DRS4DL+/DRS4D-NXT
Ethernet
Hub*
2
HUB-101
USB Hub
Transducer*
5
Control Unit
MCU-002/MCU-004 or
SD Card Unit SDU-001
CCD Camera
Touch Monitor*
4
(HDMI Output)
Event Switch
External Buzzer
Power Switch
NMEA0183 Output
Junction
Box
FI-5002
Ship’s main
12 to 24V DC
Multi-beam Sonar DFF-3DMulti-beam Sonar DFF-3D
: Standard supply
: Optional/local supply
Radar Sensor (Open)
DRS6A X-Class/DRS12A X-Class/DRS25A X-Class
DRS6A-NXT/DRS12A-NXT
/
DRS25A-NXT
Select an antenna type:
Radome or Open.
CCD Camera
Category of units
Antenna unit: Exposed to the weather.
Other units: Protected from the weather.
Multi Function
Display
TZT12F*
1
Multi Function
Display
TZT12F*
1
*
4
: The HDMI output resolution is fixed to 1280×800. To use a touch monitor for operation, its
resolution must be 1280×800 (Aspect ratio 16:9) and with HPD (Hot Plug Detection) function.
Fish Finder
Power Amplifier
DI-FFAMP
oror
*
5
: Some transducers require connection of 12-10 pin conversion cable.
*
1
: This unit has a built-in fish finder as standard.
*
2
: A maximum of 6 units of NavNet TZtouch2/3 can be connected. NavNet TZtouch2 requires software
version 7, which is to be released in Spring 2020. For configurations with TZT2BB included, a
maximum of 4 NavNet TZtouch2/3 units can be connected. NavNet TZtouch cannot be connected.
FA-40/70
Transducer
Control Unit MCU-005
PoE Hub*
3
*
3
: Use a commercially available PoE hub. "GS108PE" of NETGEAR has tested compatible.
The basic functions of the hub were verified, however the compatibility of all functions were not
checked. FURUNO cannot guarantee proper operation.
To Next Page
