2. CHART PLOTTER
2-27
If [Alarm Sound when NAVpilot is Engaged] is turned on in the [Alarm] menu, a beep
sounds to tell you that the NAVpilot is engaged or disengaged. Note that the beep
sounds regardless of the [Alarm Sound] setting.
Note: The following PGN sentences should be turned on (in the [Initial Setup] menu)
to enable use of the autopilot with this system.
2.13.2 How to show the NAVpilot control box in the data area
1. Tap [DATA] or [ROUTE] on the data area to select where to show the NAVpilot
control box.
2. Long-tap (single finger) a data box or an unoccupied area to select where to show
the NAVpilot control box. The [Edit NavData] menu appears.
3. Tap [Add NavData] to show the available data boxes.
4. Tap [NAVpilot] to show the NAVpilot control box in the area selected.
Note: The example figure below shows the Navpilot data box for the NAVpilot-300 se-
ries. The Turn/Menu button ( )is not shown on the NAVpilot-700 series, however
all other indications are the same.
• 129283: Cross Track Error
• 129284: Navigation Data
• 129285: Navigation - Route/WP Information
To Next Page
