2. CHART PLOTTER
2-23
2.11.7 How to create a route with track currently being recorded
(track back)
You can create a route with track that is currently being recorded. This method can be
useful for retracing track; for example, when you need to retrieve crab pots or the like.
The route is saved to the [Routes] list.
1. Tap the current track or own ship mark to show
the pop-up menu.
2. Tap [Track Back].
3. Enter route name, then tap [9].
A route is then created as shown below.
• Points are created along the route. Arrows on
the route point in the direction of travel.
• A thick red dashed line runs between the starting
point ("1" in the figure below) and go to point ("2"
in the figure below). A solid yellow line shows the
shortest distance between current position and
go to point.
• Route points are highlighted in yellow.
• Arrival range and cross track error lines are shown.
When you are following a track back route, the functions described below are avail-
able, from the pop-up menu. Tap the yellow line to display the pop-up menu. For de-
tails about each function, see chapter 5.
• [Stop Nav.]: Stop following the route.
• [Restart Nav.]: Restart following the route.
• [Insert]: Insert a waypoint.
• [Extend]: Extend a route from the last point on the route.
• [Name]: Enter a name for the route.
• [Rte Detail]: Open the [Route Detail] list.
Pop-up menu when
track is selected
Destination
(1st waypoint)
Waypoint
Yellow line: Shortest course from the
current position to the go to point
Cross-track
error lines
Start point of Track Back ( )
Arrival range
Arrows point in
direction of travel
Thick red dashed line: Course
between first destination and the point
where Track Back starts.
1
