Furuno NavNet TZtouch3 Series User Manual

6. RADAR
6-11
6.8.6 How to measure the bearing with the EBL
Method 1: Using the EBL/VRM box in the data area
1. Referring to section section 1.9.3, add the [EBL/VRM] data box to the [RADAR]
data area.
2. Display the data area, then tap [RADAR].
3. Tap the EBL indication in the [EBL/VRM] data box.
4. Operate the EBL so that it passes through the center of the target Drag the EBL
on the radar display, drag the knob on the slider, drag the EBL indication box, or
tap the “+” or “-” symbol. The current EBL bearing is shown in the EBL indication
box.
5. Tap [End EBL] at the top of screen to finish.
6. To clear the EBL, open the pop-up menu, the tap [EBL]→[Clear].
OR
Tap [End EBL]
to anchor EBL
and exit.
Drag slider or tap bar
(or tap +, - symbol).
Drag
EBL
XXXXX
EBL/VRM
box
Tap
Bearing
to object
Bearing
to object
