13. WEATHER OPERATIONS
13-7
If the receiver does not appear in the list, check the Antenna LED on the FURUNO
BBWX SiriusXM weather receiver and the connection between the two units. The
LED is solid violet when a normal antenna connection is detected, and off or flashing
violet in case of antenna short circuit.
• Connect the FURUNO BBWX SiriusXM weather receiver and the NavNet TZtouch3
displays then turn on both of those units. Your unit then receives WX data from the
weather receiver, which takes approximately 30 minutes.
13.3.1 How to set up for SiriusXM weather
1. Open the Home screen, then tap [Settings]→[Weather]→[Weather Data Server].
2. Tap [Sirius] then tap < to return to the menu.
3. Tap [Sirius Weather Radar].
4. Tap the SiriusXM weather radar to use, [US Now Radar] (USA) or [CanadRad]
(Canada). [US Now Radar] shows the type and level of precipitation. The amount
of precipitation increases with level.
Precipitation indication on USNowRadar.
Precipitation indication on CanadianRadar
5. Tap the close button on the title bar to finish.
Weather radar color Precipitation type Level
Light green Rain 15-19 dBz
Medium green Rain 20-29 dBz
Dark green Rain 30-39 dBz
Yellow Rain 40-44 dBz
Orange Rain 45-49 dBz
Light red Rain 50-54 dBz
Dark red Rain over 55 dBz
Light blue Snow 5-19 dBz
Dark blue Snow over 20 dBz
Light pink Mixed 5-19 dBz
Dark pink Mixed over 20 dBz
Weather radar color Level (mm per hour)
Transparent (low precipitation) 0.00 to 0.20 mm/hr
Light green 0.21 to 1.00 mm/hr
Medium green 1.01 to 4.00 mm/hr
Dark green 4.01 to 12.00 mm/hr
Yellow 12.01 to 24.00 mm/hr
Orange 24.01 to 50.00 mm/hr
Light red 50.01 to 100 mm/hr
Dark red over 100.01 mm/hr
