1. SYSTEM INTRODUCTION
1-10
1.2.4 Remote Control Unit group settings
If multiple NavNet TZtouch3 units are installed in the network, you can select the dis-
play to show on a unit, using the MCU-004 or MCU-005. Additionally, you can select
the order in which to cycle through the displays.
Note: Confirm that there are no duplicate unit nicknames in the network. If a duplicate
name is found, change the name on the [Sensor List] ([Initial Setup]→[Sensor List]).
1. From the Home screen, tap [Settings]→[Initial Setup].
2. Tap [Remote Controller Configuration] twice.
Example remote configuration - MCU-004
*: For the configurations with an MCU-005 connected, the nickname for the MCU-
005 appears.
No. Description
1 The nickname automatically assigned to the MCU-004/MCU-005.
2 The nickname assigned to the NavNet TZtouch3 unit currently being operated.
3 Setting for the unit connected to TZT12F_FB_LEFT*, controlled by MCU1.
4 Set the cycling order of units controlled by MCU1. To skip a unit, select it to [Off].
5 Setting for the unit connected to TZT19F_MB_LEFT*, controlled by MCU2.
6 Set the cycling order of units controlled by MCU2. To skip a unit, select it to [Off].
TZTL12F_FB_LEFT Switch Order
To Next Page
