APPENDIX 2 TRANSDUCER LIST

AP-16

CHIRP transducers

Other compatible transducers

CHIRP transducers (single frequency)

CHIRP transducers (dual frequency)

Model ACCU-FISH

™

Bottom

Discrimination

RezBoost

™

Remarks

TM150M No No No 300 W

B-75L No No No

B-75H No No No 600 W

B-175H No No No 1 kW

B-175L No No No

B265LH-FJ12 Yes No No

CM265LH-FJ12 Yes No No

TM265LH-FJ12 Yes No No

PM111LHG No No No 2 kW

(Requires DI-FFAMP)

CM599LHG No No No 2 to 3 kW

(Requires DI-FFAMP)

CM599LM No No No

Model ACCU-FISH

™

Bottom

Discrimination

RezBoost

™

Remarks

B150M No No No 300 W

SS75L No No No

B75M No No No 600 W

B785M No No No

SS75H No No No

SS75M No No No

B175HW No No No 1 kW

B175M No No No

B285HW No No No

B285M No No No

TM185HW No No No

TM185M No No No

Model ACCU-FISH

™

Bottom

Discrimination

RezBoost

™

Remarks

B265LH Yes No No 1 kW

B275LHW No No No

B265LM No No No

CM265LH Yes No No

CM265LM No No No

CM275LHW No No No

TM265LH Yes No No

TM265LM No No No

TM275LHW No No No
