Furuno NavNet TZtouch3 Series User Manual

FURUNO TZT12F/16F/19F
SP - 2 E4510S01A-M
200312
Estimation for bottom composition, Temperature graph
4.4 Alarm School of fish, School of fish for bottom lock
5 OTHER FUNCTIONS
5.1 AIS information AIS receiver required
5.2 DSC display 20 target max, Target data required
5.3 Instrument indication Instrument data required
5.4 Camera monitor NTSC/PAL data required
5.5 Information indication FAX/NAVTEX, Weather information (external data required)
5.6 Alarm Speed, Wind speed*, Depth*, Water temperature*,
Sea surface temperature*, Low fuel *
*: external data required
(TZT19F requires external data for all items)
6 INTERFACE
6.1 Number of port
HDMI output 1 port, TZT12F: 720p (WXGA), TZT16F/19F: 1080p (FHD)
HDMI input (TZT16F/19F only)
1 port, 1920 x 1080 (FHD) or less, HDCP, Non-interlaced
Video input (composite) 2 ports, NTSC/PAL
USB 1 port (TZT12F) or 2 ports (TZT16F/19F) , USB2.0,
for touch-monitor and control unit
LAN 2 ports, Ethernet 100Base-TX
NMEA2000 1 port
Serial 1 port, NMEA0183 output
Contact closure 2 port, event switch and external power switch
SD card slot 1 port, micro-SDXC
6.2 Wireless LAN IEEE802.11b/g/n
Transmit frequency 2.412 to 2.462 GHz
Output power 11 dBm max.
6.3 NMEA0183 sentences
Output AAM, APB, BOD, DBT, DPT, GGA, GLL, GNS, GSA, GSV, RMB,
RMC, RTE, TTM, VDM, VTG, WPL, XTE, ZDA
6.4 NMEA2000 PGN
Input 065280, 126992, 126993, 126996, 127237, 127245, 127251, 127257, 127488,
127489, 127505, 128259, 128267, 129025, 129026, 129029, 129330, 129038,
129039, 129040, 129041, 129291, 129538, 129540, 129793, 129794, 129798,
129801, 129802, 129808, 129809, 129810, 130306, 130310, 130311, 130312,
130313, 130314, 130316, 130577, 130578, 130817, 130818, 130820, 130822,
130823, 130826, 130827, 130828, 130880
Output 126992, 126993, 126996, 127250, 127251, 127257, 127258, 128259, 128267,
128275, 129025, 129026, 129029, 129033, 129283, 129284, 129285, 130306,
130310, 130311, 130312, 130313, 130314, 130316
7 POWER SUPPLY
7.1 Multi function display
TZT12F 12-24 VDC: 2.3-1.2 A
TZT16F 12-24 VDC: 4.3-2.2 A
