GE HEALTHCARE
DIRECTION FC091194, REVISION 11 VIVID 7 SERVICE MANUAL
Chapter 3 - System Setup 3 - 119
3-11-8 Verification of a Connection Set Up to EchoPAC PC - Software v2.x (cont’d)
10.)Select the SERVICES
tab (located near the top of the window).
11.)Select the EchoPAC PC Workstation you want to connect to, from the “Name” drop-down menu. In
this example, it is called “EchoPAC7-000000”.
Figure 3-129 Dataflow Services
Figure 3-130 Dataflow Services, Choices and Setup
Name drop-down
menu
SERVICES
tab
Local Archive - Local
Storage
Select Server
Name drop-down
menu
To Next Page
