Cinterion

®

EHS6 AT Command Set 

16.12 AT^SAFH

 EHS6_ATC_V03.001 15/12/3

Confidential / Released

Page 409 of 513

EXAMPLE 3

OK

+CIEV: voiceprompt,1

Playback starts.

+CIEV: voiceprompt,0

Playback has finished.

AT^SAFH=4

Store recorded audio file to FFS.

^SAFH: 0

No error.

OK

+CIEV: voiceprompt,1

Playback starts.

+CIEV: voiceprompt,0

Playback has finished.
