Lexmark 940e - X Color Laser Service Manual

2-58 Service Manual
7510
5
Check the sensor (tray 3 feed-out) for proper operation.
1. Enter the Diagnostics Menu.
2. Touch INPUT TRAY TESTS.
3. Touch Sensor test.
4. Touch Tray 3.
5. Touch Feed-out.
Does the display on the operator panel, change every
time the sensing area of the above sensor is interrupted
or blocked?
Go to step 7.
Go to step 6.
6
Check the sensor (tray 3 feed-out) for proper
connection.
Is the above component properly connected?
Replace the sensor
(tray 3 feed-out).
Replace the
connection.
7
Check the media feed lift motor in media tray 3 for
proper operation.
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Printer motor tests.
4. Touch Tray 3 media feed/lift motor.
Does the above component operate properly?
Go to step 9. Skip to step 8.
8
Check the media feed lift motor for proper connection.
Is the above component properly connected?
Replace the media
feed lift motor.
Go to “Media feed
lift motor removal”
on page 4-113.
Replace the
connection.
9
Perform a print test.
Does the error continue?
Replace the 1TM
controller card
assembly or the 3TM
controller card
assembly or the TTM
controller card
assembly.
Go to “1X 500-
sheet drawer
(1TM)–1TM
controller card
assembly removal”
on page 4-252“3X
500-sheet drawer
(3TM)–3TM
controller card
assembly removal”
on page 4-231 or
“2000-sheet dual
input (TTM)–TTM
controller card
assembly removal”
on page 4-205.
Go to step 10.
Problem solved.
Step Check Yes No
