Repair information 4-247

7510

1X 500-sheet drawer (1TM)—separation roll one-way friction clutch removal

1. Remove the media tray assembly.

2. Remove the separation roll. See “1X 500-sheet drawer (1TM)–separation roll removal” on page 4-248.

3. Remove the separation roll spacer (A).

4. Remove the separation roll one-way friction clutch (B).

Seal

Sea
