Diagnostic information 2-177
7510
956.02 RIP card assembly cooling fan failure
956.03 RIP card assembly FPGA failure
980.00 Communication error with 1TM, 3TM, or TTM assembly
Step Check Yes No
1 Perform a POR.
Does the error occur when the power is turned off/on?
Go to step 2. Perform several
print tests.
If the problem
remains, go to
step 2.
2 Turn the printer off for 60 seconds.
Does the error occur when the power is turned off/on again?
Go to step 3. Problem solved.
3 Checking the RIP card assembly cooling fan and heatsink
attachment.
Is the above fan attached properly?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-73.
Reattach the RIP
card assembly
cooling fan and
heatsink.
Step Check Yes No
1 Perform a POR.
Does the error occur when the power is turned off/on?
Go to step 2. Perform several
print tests.
If the problem
remains, go to
step 2.
2 Turn the printer off for 60 seconds.
Does the error occur when the power is turned off/on again?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-73.
Problem solved.
Step Check Yes No
1 Check the 1TM, 2TM or TTM controller card assembly
and the printer engine card assembly for proper
connection.
Is the above component properly connected?
Go to step 2. Replace the
connection.
To Next Page
