Parts catalog 7-33

7510

Assembly 30: Electrical 2

Asm-

index

Part

number

FRUs/

mach

Units/

FRU

Description

1 40X3764 1 1 AC drive card bracket assembly 110 V (this comes assembled)

1 40X3765 1 1 AC drive card bracket assembly 220 V (this comes assembled)

2 40X3766 1 1 Outlet power panel cable assembly
