Diagnostic information 2-99
7510
294.02 Sensor (ADF pre-registration) lag jam (inverting)
9
Check the inverter solenoid assembly for proper operation.
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch Inverter solenoid.
Does the above component operate properly?
Go to step 11. Go to step 10.
10
Check the inverter solenoid assembly for proper
connection.
Is the above component properly connected?
Replace the
inverter solenoid
assembly.
Go to “Inverter
solenoid
assembly
removal” on
page 4-139.
Replace the
connection.
11
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the ADF
controller card
assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-138.
Go to step 12.
Problem solved.
12
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-73.
Problem solved.
Step Check Yes No
1 Check the original document condition.
Is the original document free of paper clips and staples as
well as damage such as creases, tears, holes or excessive
wear?
Go to step 2. Remove damaged
original document
and replace with a
new undamaged
original document.
Perform a ADF
test. If the problem
remains, go to step
2.
