1-22 Service Manual

7510

CMY developer drive motor assembly

The CMY developer drive motor assembly uses a DC brushless motor to drive the three color developer unit

assemblies.

K developer clutch

This clutch is used to engage the K developer unit assembly and is driven by the K-developer transfer drive

motor assembly.

CMYK toner add motor assembly

K developer

clutch

CMY developer drive

motor assembly

Y toner add motor

Y toner add assembly

M toner add motor

M toner add assembly

C toner add motor

C toner add assembly

K toner add motor

K toner add assembly
