Lexmark 940e - X Color Laser Service Manual

Diagnostic information 2-135
7510
902.03 General lower engine error fuse #1
3
Check the waste toner agitator motor assembly cables and
any associated cables for damage.
Are the above components free from crimps and damage?
Go to step 4. Repair or replace
the appropriate
cable assemblies
or the waste toner
agitator motor
assembly.
Go to “Waste
toner agitator
motor assembly
removal” on
page 4-44.
4
Perform a POR.
Does the error occur when the power is turned off/on?
Replace the upper
printer engine card
assembly.
Go to “Upper
printer engine
card assembly
removal” on
page 4-77.
Problem solved.
Step Check Yes No
1 Perform a POR.
Does the error occur when the power is turned off/on?
Go to step 2. Perform several
print tests.
If the problem
remains, go to
step 2.
2
Check the duplex drive motor assembly cables and any
associated cables for damage.
Are the above components free from crimps and damage?
Go to step 3. Repair or replace
the appropriate
cable assemblies
or replace the
duplex unit
assembly.
Go to “Duplex
unit assembly
removal” on
page 4-10.
3
Perform a POR.
Does the error occur when the power is turned off/on?
Replace the lower
printer engine card
assembly.
Go to “Lower
printer engine
card assembly
removal” on
page 4-80.
Problem solved.
Step Check Yes No
