Diagnostic aids 3-25
7510
Trans Belt HP Fail Clear
To perform the Trans Belt Fail Clear Test:
1. Touch Trans Belt Fail Clear from the Diagnostics Menu.
2. Touch Trans Belt HP Fail Clear.
Trans Belt HP Fail Clear Testing.... appears on the LCD.
Press Stop to return to Trans Blet PH Fail Clear.
Dev Unit Reset
To perform the Dev Unit Reset Test:
1. Touch Dev Unit Reset from the Diagnostics Menu.
The following tests appear on the LCD:
When each test completes, the LCD returns to Dev Unit Reset.
Fuser Temp Fail Clear
To perform the Fuser Temp Fail Clear Test:
1. Touch Fuser Temp Fail Clear from the Diagnostics Menu.
2. Touch Fuser Temp Fail Clear.
Fuser Temp Fail Clear Testing.... appears on the LCD.
When testing is complete, the LCD returns to Fuser Temp Fail Clear.
ATC SENSOR FAILURE CLEAR
To perform the ATC Sensor Failure Clear Test:
1. Touch ATC SENSOR FAILURE CLEAR from the Diagnostics Menu.
The following tests appear on the LCD:
When each test completes, the LCD returns to ATC SENSOR FAILURE CLEAR.
Touch the following: Appears on the LCD:
Y Channel Y Channel Testing...
M Channel M Channel Testing...
M Channel C Channel Testing...
K Channel K Channel Testing...
Touch the following: Appears on the LCD:
Y Channel (925.00) Y Channel Testing...
M Channel (925.01) M Channel Testing...
M Channel (925.02) C Channel Testing...
K Channel (925.02) K Channel Testing...
