7-50 MFP Service Manual

7510

Assembly 40: ADF motor unit

Asm

Index

Part

number

Units/

mach

Units/ kit

or pkg

Description

1 40X2327 1 1 ADF feed motor assembly (this comes assembled)

2 40X2223 13 1 Sensor (sheet through)

3 40X2229 1 1 Tension spring

4 40X2325 1 1 ADF registration motor

Default Chapter3
