Lexmark 940e - X Color Laser Service Manual

2-102 Service Manual
7510
295.00 Size mismatch jam (mix-size)
12
Check the ADF registration motor for proper operation.
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch ADF registration drv mtr.
5. Touch Forward or reverse.
Does the above component operate properly?
Go to step 14. Go to step 13.
13
Check the ADF registration motor for proper connection.
Is the above component properly connected?
Replace the ADF
registration
motor.
Go to “ADF
registration
motor removal”
on page 4-159.
Replace the
connection.
14
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the ADF
controller card
assembly.
Go to “ADF
controller card
assembly
removal” on
page 4-138.
Go to step 15.
Problem solved.
15
Place an undamaged document in the ADF, and perform a
ADF test.
Does the error remain?
Replace the RIP
card assembly.
Go to “RIP card
assembly
removal” on
page 4-73.
Problem solved.
Step Check Yes No
1 Check the document tray media guide position.
Are the document tray media guides set correctly?
Go to step 2. Adjust the
document tray
media guides to
the proper
position.
Step Check Yes No
