Lexmark 940e - X Color Laser Service Manual

Diagnostic information 2-101
7510
8
Check the ADF feed drive motor assembly for proper
operation.
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch ADF feed drv mtr.
Does the above component operate properly?
Go to step 10. Go to step 9.
9
Check the ADF feed drive motor assembly for proper
connection.
Is the above component properly connected?
Replace the ADF
feed drive motor
assembly.
Go to “ADF feed
drive motor
assembly
removal” on
page 4-134.
Replace the
connection.
10
Check the inverter solenoid assembly for proper operation.
Caution: When performing motor tests,
ensure that all cover and door interlock
switches are overridden.
1. Enter the Diagnostics Menu.
2. Touch MOTOR TESTS.
3. Touch Scanner Motor Tests.
4. Touch Inverter solenoid.
Does the above component operate properly?
Go to step 12. Go to step 11.
11
Check the inverter solenoid assembly for proper connection.
Is the above component properly connected?
Replace the
inverter solenoid
assembly.
Go to “Inverter
solenoid
assembly
removal” on
page 4-139.
Replace the
connection.
Step Check Yes No
