Lexmark 940e - X Color Laser Service Manual

4-118 Service Manual
7510
Scanner right cover removal
1. Remove the two screws securing the scanner right cover (A) to the scanner unit assembly.
2. Disengage the rear side of scanner right cover (A) from the scanner unit assembly, and shift the scanner right
cover (A) rearward.
3. Release the two hooks securing the front side of the scanner right cover (A), and remove the scanner right cover
(A).
Scanner top rear cover removal
1. Open the ADF left cover assembly.
2. Remove the two screws securing the scanner top rear cover (A) to the machine.
3. Remove the scanner top rear cover (A).
A
