4-116 Service Manual

7510

Platen cushion removal

1. Open the ADF unit assembly.

2. Gently pull off the platen cushion (A) from the ADF.

Note: Before reinstalling the platen cushion (A), position the ADF in its upright position, and place the platen

cushion (A) on the large platen glass (B) flush with the left and top edges. Gently close the ADF to attach the

platen cushion (A) to the ADF.

Platen guide

0.5+/-0.2mm
