7-88
MFP Service Manual
7510
Assembly 65: TTM left door
Asm-
index
Part
number
FRUs/
mach
Units/
FRU
Description
1
40X3844
1
1
TTM left do
or assembly (this comes assembled)
2
40X3821
1
1
Switch (tray module le
ft door interlock)
2
1
789
