Lexmark 940e - X Color Laser Service Manual

Repair information 4-5
7510
Rear cover assembly removal
1. Remove the blind cover (A).
2. Remove all connectors and power cords from the rear of the machine.
3. Remove the four screws securing the rear cover assembly (B) to the machine.
4. Remove the rear cover assembly (B).
B
A
Connectors

Lexmark 940e - X Color Laser Specifications

General

Brand	Lexmark
Model	940e - X Color Laser
Category	All in One Printer
Language	English
